Fantech FADE Direct Drive Propeller Fans

A series of sidewall propeller fans designed for structural stability with a slim profile for conservation of space and safety. All FADE Series fans have aerodynamically designed propeller blades and motor rotor assembled as one integral unit.  All FADE fans include motor-side guards as standard.

FADE Series motors are a totally enclosed Class B, direct drive external rotor type with sealed self lubricating bearings and automatic reset thermal over-load protection. Motors are capable of operating in ambient air or air stream temperatures of up to 100 F. FADE Series fans are 100% speed controllable through a decrease in voltage by using either a solid state or transformer type control.

model description usually ships price QTY
FADE 8-4 Fantech FADE Propeller Fans. 1/25 Hp 115/1/60 - 304 cfm. 4.1 sones at 0.1 inches SP. 1 Day. In-stock $198.00
FADE 10-4 Fantech FADE Propeller Fans. 1/15 Hp 115/1/60 - 624 cfm. 7.9 sones at 0.1 inches SP. 1 Day. In-stock $233.00
FADE 12-4 Fantech FADE Propeller Fans. 1/8 Hp 115/1/60 - 1208 cfm. 9.4 sones at 0.1 inches SP. 1 Day. In-stock $274.00
FADE 12-4 WHD Fantech FADE Propeller Fans. 1/8 Hp 115/1/60 - 1208 cfm. 9.4 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $489.00
FADE 14-4 Fantech FADE Propeller Fans. 1/4 Hp 115/1/60 - 1839 cfm. 9.6 sones at 0.1 inches SP. 1 Day. In-stock $344.00
FADE 14-4 WHD Fantech FADE Propeller Fans. 1/4 Hp 115/1/60 - 1839 cfm. 9.6 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $539.00
FADE 16-4 Fantech FADE Propeller Fans. 1/3 Hp 115/1/60 - 3054 cfm. 12.0 sones at 0.1 inches SP. 1 Day. In-stock $399.00
FADE 16-4 WHD Fantech FADE Propeller Fans. 1/3 Hp 115/1/60 - 3054 cfm. 12.0 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $672.00
FADE 18-4 Fantech FADE Propeller Fans. 3/4 Hp 115/1/60 - 4115 cfm. 14.3 sones at 0.1 inches SP. 2-3 days $629.00
FADE 18-4 WHD Fantech FADE Propeller Fans. 3/4 Hp 115/1/60 - 4115 cfm. 14.3 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $845.00
FADE 20-4 Fantech FADE Propeller Fans. 1.0 Hp 115/1/60 - 4949 cfm. 16.4 sones at 0.1 inches SP. 2-3 days $749.00
FADE 20-4 WHD Fantech FADE Propeller Fans. 1.0 Hp 115/1/60 - 4949 cfm. 16.4 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $1019.00
FADE 20-4/3 Fantech FADE Propeller Fans. 1.0 Hp 208-230-460/3/60 - 4949 cfm. 16.4 sones at 0.1 inches SP. 2-3 days $732.00
FADE 20-4/3 WHD Fantech FADE Propeller Fans. 1.0 Hp 208-230-460/3/60 - 4949 cfm. 16.4 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $984.00
FADE 20-6 Fantech FADE Propeller Fans. 1/2 Hp 115/1/60 - 3693 cfm. 10.7 sones at 0.1 inches SP. 2-3 days $679.00
FADE 20-6 WHD Fantech FADE Propeller Fans. 1/2 Hp 115/1/60 - 3693 cfm. 10.7 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $957.00
FADE 22-6 Fantech FADE Propeller Fans. 3/4 Hp 115/1/60 - 5629 cfm. 12.0 sones at 0.1 inches SP. 2-3 days $938.00
FADE 22-6 WHD Fantech FADE Propeller Fans. 3/4 Hp 115/1/60 - 5629 cfm. 12.0 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $1237.00
FADE 22-6/3 Fantech FADE Propeller Fans. 3/4 Hp 208-230-460/3/60 - 5629 cfm. 12.0 sones at 0.1 inches SP. 2-3 days $899.00
FADE 22-6/3 WHD Fantech FADE Propeller Fans. 3/4 Hp 208-230-460/3/60 - 5629 cfm. 12.0 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $1189.00
FADE 25-6 Fantech FADE Propeller Fans. 1.5 Hp 115/1/60 - 7858 cfm. 14.8 sones at 0.1 inches SP. 2-3 days $1109.00
FADE 25-6 WHD Fantech FADE Propeller Fans. 1.5 Hp 115/1/60 - 7858 cfm. 14.8 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $1399.00
FADE 25-6/3 Fantech FADE Propeller Fans. 1.5 Hp 208-230-460/3/60 - 7858 cfm. 14.8 sones at 0.1 inches SP. 2-3 days $1019.00
FADE 25-6/3 WHD Fantech FADE Propeller Fans. 1.5 Hp 208-230-460/3/60 - 7858 cfm. 14.8 sones at 0.1 inches SP. INCLUDES ASSEMBLED WALL HOUSING AND GRAVITY DAMPER. 2-3 days $1299.00
add to basket

real-time shipping quotes are available before checkout on your shopping cart page

Do you have questions about the products on this page?

Click on the ? image on the left or this link to ask us your questions!
#1 Q:   What product of yours do you recommend to cool down my 2 car garage in Phoenix AZ?
A:   These are a good choice for moving large amounts of air. We see them used in attic and garage cooling applications all the time. Keep in mind these fans just move air so if the air outside is 110 F you might not be doing much cooling.

       Asked on 2019-06-06 by ALPHAGUY
#2 Q:   I have a FADE 14-4 fan that I would like to use to draw air through the house at night and would like to be certain that the WC 15 would be ok for this. I want to mount it on the wall as opposed to the attic for convenience sake.
A:   Yes, the WC15 is fine for the 14-4 fan.

       Asked on 2018-07-06 by Tim
