S&P Series 556 Rear Flanged General Purpose Shutters

S&P Series 556 Rear Flanged General Purpose Shutters

The Model 556 is a rear flanged general purpose exhaust shutter. The frame is galvanized steel with mill finish aluminum blades. The blades have a galvanized reinforcement strip across the top of each blade for added strength and counter balancing efficiency. The blades have a felt seal on the leading edge for quiet closing and better protection from the weather. Ideal for use with direct-drive or belt-driven exhaust fans. Recommended for vertical mount exhaust applications only.

FEATURES:
• .037 gauge galvanized steel.
• Tog-L-Loc and tabbed corners provide rigidity and durability.
• 26 gauge 3105 mill finish aluminum blades.
• Maximum recommended velocity is 2,500 FPM
• Temperature: -40 F to 180 F

model description usually ships price QTY
556012 S&P 12" X 12" series 556 automatic wall shutter. Max velocity of 2500 FPM. 1 panel. 5-6 Weeks $72.50
556016 S&P 16" X 16" series 556 automatic wall shutter. Max velocity of 2500 FPM. 1 panel. 5-6 Weeks $88.80
556020 S&P 20" X 20" series 556 automatic wall shutter. Max velocity of 2500 FPM. 1 panel. 5-6 Weeks $107.50
556024 S&P 24" X 24" series 556 automatic wall shutter. Max velocity of 2500 FPM. 1 panel. 5-6 Weeks $124.70
556030 S&P 30" X 30" series 556 automatic wall shutter. Max velocity of 2500 FPM. 1 panel. 5-6 Weeks $149.60
556036 S&P 36" X 36" series 556 automatic wall shutter. Max velocity of 2500 FPM. 1 panel. 5-6 Weeks $200.30
556042 S&P 42" X 42" series 556 automatic wall shutter. Max velocity of 2500 FPM. 2 panels. 5-6 Weeks $290.60
556048 S&P 48" X 48" series 556 automatic wall shutter. Max velocity of 2500 FPM. 2 panels. 5-6 Weeks $339.70
EAS1232MTR S&P damper motor option for 1 panel shutters. 115/230 VAC 60 Hz power open, spring return motor. Ships loose. 5-6 Weeks $221.30
EAS3850MTR S&P damper motor option. 115/230 VAC 60 Hz power open, spring return motor. For 42x42 and 48x48 shutters. Ships loose. 5-6 Weeks $291.40
add to basket

real-time shipping quotes are available before checkout on your shopping cart page

S&P 556 Shutters

Do you have questions about the products on this page?

Click on the ? image on the left or this link to ask us your questions!
#1 Q:   Is this a gravity type shutter that opens/closes based on airflow from the exhaust fan, or does it require a motor or manual operation to open?
A:   This is a gravity shutter that opens with fan airflow. No motor.

       Asked on 2016-08-02 by Bill
