Canarm ADD Series Direct Drive Wall Exhaust Fans 1 Phase

Canarm ADD Series Direct Drive Wall Exhaust Fans 1 Phase

These exhaust fans are typically used for high volume, high static pressure applications.  The series ADD is designed and constructed for efficient & economical operations and is direct drive, therefore  requiring little or no maintenance.  Heavy duty airfoil cast aluminum blades are standard to ADD series fans providing maximum performance at low sound levels. 1 PHASE MOTOR MODELS.

  • Heavy gauge steel fan panel with deep spun and flared venturi for maximum efficiency.
  • Heavy gauge welded steel motor supports.
  • Cast aluminum airfoil blades.
  • TEFC motors are standard.
  • Note: These fans can be combined with Explosion Proof Motors for use in hazardous locations.
model description usually ships price QTY
ADD12T10033B Canarm 12" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 1/3HP, 115/230V motor. 2-3 Weeks $776.80
ADD12T10033C Canarm 12" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 1/3HP, 115/230V motor. 2-3 Weeks $1104.30
ADD12CBS10033B Canarm 12" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 1 phase, 1/3HP, 115/230V motor. 2-3 Weeks $994.70
ADD14CBS10033B Canarm 14" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 1 phase, 1/3HP, 115/230V motor. 2-3 Weeks $1045.10
ADD14T10033B Canarm 14" ADD direct drive wall fan. HD airfoil cast aluminum blade.1 phase, 1/3HP, 115/230V motor. 2-3 Weeks $768.00
ADD14T10033C Canarm 14" ADD direct drive wall fan. HD airfoil cast aluminum blade.1 phase, 1/3HP, 115/230V motor. 2-3 Weeks $1114.90
ADD16CBS10050B Canarm 16" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 1 phase, 1/2HP, 115/230V motor. 2-3 Weeks $1165.30
ADD16T10050B Canarm 16" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 1/2HP, 115/230V motor. 2-3 Weeks $877.50
ADD16T10033C Canarm 16" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 1/3HP, 115/230V motor. 2-3 Weeks $1185.40
ADD18T10075B Canarm 18" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 3/4HP, 115/230V motor. 2-3 Weeks $1283.10
ADD18T10033C Canarm 18" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 1/3HP, 115/230V motor. 2-3 Weeks $1207.90
ADD18CBS10075B Canarm 18" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 1 phase, 3/4HP, 115/230V motor. 2-3 Weeks $1316.30
ADD20T10033C Canarm 20" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 1/3HP, 115/230V motor. 2-3 Weeks $1476.70
ADD20T10100B Canarm 20" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 1HP, 115/230V motor. 2-3 Weeks $1276.60
ADD20CBS10100B Canarm 20" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 1 phase, 1HP, 115/230V motor. 2-3 Weeks $1676.30
ADD24T10050C Canarm 24" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 0.5HP, 115/230V motor. 2-3 Weeks $1662.60
ADD24T10100C Canarm 24" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 1HP, 115/230V motor. 2-3 Weeks $1879.90
ADD24T10150B Canarm 24" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 1.5HP, 115/230V motor. 2-3 Weeks $1447.70
ADD24T10200B Canarm 24" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 2HP, 115/230V motor. 2-3 Weeks $1605.20
ADD24T10300B Canarm 24" ADD direct drive wall fan. HD airfoil cast aluminum blade. 3HP, 208-230V, 1 phase motor. 2-3 Weeks $1871.10
ADD24CBS10150B Canarm 24" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 1 phase, 1.5HP, 115/230V motor. 2-3 Weeks $1938.00
ADD24CBS10200B Canarm 24" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 1 phase, 2HP, 115/230V motor. 2-3 Weeks $2104.90
ADD24CBS10300B Canarm 24" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 3HP, 208-230V, 1 phase motor. 2-3 Weeks $2385.60
ADD30T10100C Canarm 30" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 1HP, 115/230V motor. 2-3 Weeks $3061.80
ADD30T10300B Canarm 30" ADD direct drive wall fan. HD airfoil cast aluminum blade. 3HP, 208-230V, 1 phase motor. 2-3 Weeks $2133.40
ADD30T10500B Canarm 30" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 5HP, 208-230V motor. 2-3 Weeks $2167.70
ADD30CBS10300B Canarm 30" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 3HP, 208-230V, 1 phase motor. 2-3 Weeks $2599.30
ADD30CBS10500B Canarm 30" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 1 phase, 5HP, 208-230V motor. 2-3 Weeks $2849.20
ADD36T10500B Canarm 36" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 5HP, 208-230V motor. 2-3 Weeks $2392.70
ADD36T10750B Canarm 36" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 7.5HP, 208-230V motor. 2-3 Weeks $3250.70
ADD36T11000B Canarm 36" ADD direct drive wall fan. HD airfoil cast aluminum blade. 1 phase, 10HP, 208-230V motor. 2-3 Weeks $4164.30
ADD36CBS10500B Canarm 36" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 1 phase, 5HP, 208-230V motor. 2-3 Weeks $3210.40
ADD36CBS11000B Canarm 36" ADD direct drive wall fan. HD airfoil cast aluminum blade, cabinet, backguard and shutter. 1 phase, 10HP, 208-230V motor. 2-3 Weeks $5047.10
add to basket

real-time shipping quotes are available before checkout on your shopping cart page



canarm leader ADD wall exhauster series

canarm leader ADD wall exhauster series
