Canarm Leader Fan

Canarm Leader Fan Series SD Wall Exhaust Fans

SD Series fans are available in single, two and variable speed models. All variable speed standard fans use an energy efficient variable speed, dual voltage motor and blade combination.

• Single, two and variable speed models are available.
• All fans use a totally enclosed, thermally protected motor.
• The rugged steel welded box housing has a durable powder coated finish.
• Aluminum louver shutters are supported by long life nylon bushings (30" and 36" have PVC louvers).
• 8" - 24" models have heavy wire chrome plated OSHA guards on intake side of fan. 30" & 36" models have grey powder coated guards.

model description usually ships price QTY
S8-B2 Canarm/Leader SD Series direct drive exhaust fans. 8 inch, 360/300 nominal CFM, 2 speed, 115V, 1 phase. 2-6 Days $136.80
S10-B2 Canarm/Leader SD Series direct drive exhaust fans. 10 inch, 690/580 nominal CFM, 2 speed, 115V, 1 phase. 2-6 Days $143.40
S12-E1 Canarm/Leader SD Series direct drive exhaust fans. 10 inch, 1640 nominal CFM, 1 speed, 115, 1 phase. 2-6 Days $211.20
S12-E2 Canarm/Leader SD Series direct drive exhaust fans. 12 inch, 1650/1090 nominal CFM, 2 speed, 115V, 1 phase. 2-6 Days $266.40
S12-EVD Canarm/Leader SD Series direct drive exhaust fans. 12 inch, 1650 nominal CFM, variable speed, 115/230V, 1 phase. 2-6 Days $246.60
S14-E1 Canarm/Leader SD Series direct drive exhaust fans. 14 inch, 2170 nominal CFM, 1 speed, 115, 1 phase. 2-6 Days $214.80
S14-E2 Canarm/Leader SD Series direct drive exhaust fans. 14 inch, 2180/1350 nominal CFM, 2 speed, 115V, 1 phase. 2-6 Days $266.40
S16-E1 Canarm/Leader SD Series direct drive exhaust fans. 16 inch, 2370 nominal CFM, 1 speed, 115, 1 phase. 2-6 Days $223.80
S16-E2 Canarm/Leader SD Series direct drive exhaust fans. 16 inch, 2380/1640 nominal CFM, 2 speed, 115V, 1 phase. 2-6 Days $273.00
S16-EVD Canarm/Leader SD Series direct drive exhaust fans. 16 inch, 2370 nominal CFM, variable speed, 115/230V, 1 phase. 2-6 Days $294.00
S18-F1 Canarm/Leader SD Series direct drive exhaust fans. 18 inch, 3200 nominal CFM, 1 speed, 115, 1 phase. 2-6 Days $232.20
S18-FVD Canarm/Leader SD Series direct drive exhaust fans. 18 inch, 3150 nominal CFM, variable speed, 115/230V, 1 phase. 2-6 Days $327.00
S18-F2 Canarm/Leader SD Series direct drive exhaust fans. 18 inch, 3200/2100 nominal CFM, 2 speed, 115V, 1 phase. 2-6 Days $313.80
S20-F1 Canarm/Leader SD Series direct drive exhaust fans. 20 inch, 3420 nominal CFM, 1 speed, 115, 1 phase. 2-6 Days $266.40
S20-F2 Canarm/Leader SD Series direct drive exhaust fans. 20 inch, 3440/2300 nominal CFM, 2 speed, 115V, 1 phase. 2-6 Days $334.80
SD24-F1 Canarm/Leader SD Series direct drive exhaust fans. 24 inch, 5000 nominal CFM, 1 speed, 115, 1 phase. 2-6 Days $336.00
SD24-GVD Canarm/Leader SD Series direct drive exhaust fans. 24 inch, 5050 nominal CFM, variable speed, 115/230V, 1 phase. 2-6 Days $383.40
SD30-G1D Canarm/Leader SD Series direct drive exhaust fans. 30 inch, 8000 nominal CFM, 1 speed, 115/230V, 1 phase. 2-6 Days $476.40
SD36-G1D Canarm/Leader SD Series direct drive exhaust fans. 36 inch, 10000 nominal CFM, 1 speed, 115/230V, 1 phase. 2-6 Days $513.00
add to basket

real-time shipping quotes are available before checkout on your shopping cart page



canarm leader SD wall exhaust fans

Do you have questions about the products on this page?

Click on the ? image on the left or this link to ask us your questions!
#1 Q:   what is the depth of the housing when the louvers are open? How thick a wall can this fit into? I have a grill on the outside of the wall already dont want the louvers to hit the back of the grill.
A:   Depends on the model/size you are looking at. Please have a look at the dimensions in the catalog sheet: http://hvacquick.com/catalog_files/Leader_SD_Wall_Catalog.pdf For the blade size divide the E dim by the number of louvers (N value)

       Asked on 2017-01-23 by Dan Gallo
#2 Q:   What size duct fits these fans?
A:   These are typically not duct mounted but through a wall with no ducting. For opening size for each model see the framing dimensions on the Specs page or in the catalog.

       Asked on 2015-05-26 by Joel
